What is CDR FoodLabs for Oils & Fats?

CDR FoodLabs is an innovative analyzer for oils and fats featuring LED-based photometric technology. Its robust performance and unique features are easy to use and versatile in nature, enabling a wide panel of parameters, without the need for multiple instruments. The advanced testing device for oils and fats helps detect contaminants and chemical residues, identify quality inconsistencies and safeguard the product.

What Can You Analyze?

All types of oils and fats of animal and vegetable origin can be analyzed to determine Acidity (FFA), Peroxide value (PV), p-Anisidine value (AnV), Soaps, Total polyphenols/stability index in olive oil, iodine value in palm oil, coconut and kernel oil. CDR FoodLabs is a user-friendly and cost-efficient instrument providing a competitive advantage for oil and fat producing industries.

Where Can You Analyze?

In laboratories and oil plants.

Analysis Time

In less than 5 minutes.

Measurement Principle

Photometric technology

Measuring Parameters

Complete analysis panel for oils and fats to measure acidity, peroxide value, p-Anisidine value, soaps and polyphenols in olive oil, and iodine value in palm oil, coconut and kernel oil.

Download Brochure

Features

Swift & Time Saving Analysis

CDR FoodLabs accelerates analysis procedures by simultaneously analyzing 16 samples. By constantly monitoring the process, this multi-tasking analyzer swiftly measures multiple parameters delivering accurate results within minutes.

Robust & Reliable

Our solutions are trusted in the industry for their reliability and efficiency in delivering results with precision. With the use of advanced photometric technology featuring LED emitters at fixed wavelengths, the device guarantees high sensitivity, a wide measuring range and exceptional repeatability of test results.

Ease Of Use

CDR FoodLabs has been engineered in such a way that it can be used not only in the laboratory but also on the production line for real-time results. It is simple and can be easily operated by any personnel without the need for technical training. The analysis methods can be easily performed in a few easy steps. Start by adding the sample to the pre-filled reagent, follow the displayed instructions and if required, the HELP function will guide you through the process. The results are automatically calculated, displayed and then printed out.

Technical Specifications

Included calibrations

TEST	Measuring range	Resolution	Repeatability	Test time
Acidity (FFA)	0.01 - 1.10 % of oleic acid	0.01 % of oleic acid	0.02 % of oleic acid	1 min
	1.0 – 3.5 % of oleic acid	0.1 % of oleic acid	0.1 % of oleic acid	1 min
	1.0 – 26.0 % of oleic acid	0.1 % of oleic acid	0.5 % of oleic acid	1 min
Peroxides value	0.01 – 5.50 meqO²/Kg	0.01 meqO²/Kg	0.05 meqO²/Kg	3 mins
	0.30 – 25.00 meqO²/Kg	0.01 meqO²/Kg	0.24 meqO²/Kg	3 mins
	1.0 – 50.0 meqO²/Kg	0.1 meqO²/Kg	0.5 meqO²/Kg	3 mins
	4.0 – 550.0 meqO²/Kg	0.1 meqO²/Kg	5.2 meqO²/Kg	3 mins
p-Anisidine Value	0.5 – 100.0 AnV	0.1 AnV	0.7 AnV	1 min
Soaps	1 – 300 ppm	1 ppm	9 ppm	1 min
	50 – 1350 ppm	1 ppm	38 ppm	1 min
	100 – 3000 ppm	1 ppm	77 ppm	1 min
Iodine Value (on palm, coconut and kernel oil)	2 – 100 I. V.	1 I. V.	2 I. V.	1 min
Polyphenols (on olive oil)	200 – 1000 mg/Kg tyrosol	1 mg/Kg tyrosol	34 mg/Kg tyrosol	5 mins
Oil Stability Index (OSI)	9.0-40.0 h	0.1 h	0.8 h

Easy Steps For Effortless Results

Solutions For Seamless Business Operations

At Everest Instruments, our services do not end with a sale or a purchase. It is only the beginning of a journey of trust and continuity, ensuring your business operations are safeguarded throughout. Our cutting-edge devices simplify the entire food and beverage industry process. Explore our range of cost-efficient and automated instruments that are compact, lightweight and designed to improve overall product quality.

Download Brochure

Testimonials

Frequently Asked Questions

What is CDR FoodLab?

CDR FoodLab is a line of chemical analysis systems for quality and process control of foods and beverages. It can be used in the laboratory or on the production line, even without the need for specialised personnel.

What are the conditions required for a CDR FoodLab analyzer to work?

The CDR FoodLab analyzer is a device that can perform chemical analyses on various types of food and beverages, such as nuts, seeds, oils, wine, beer, etc1 Some of the conditions required for the analyzer to work are:

No use of toxic solvents
Reading and incubation cells are thermostated at 37 °C
No organic acid based cleaning substances should be applied

What Can you analyse in CDR FoodLab Oils & Fat

With CDR FoodLab®, chemical analyses can be performed of all types of oils and fats of animal and vegetable origin. The sample can be analysed in the unaltered state or after a simple preparation set up by CDR laboratories. The analyses that can be carried out are:

Free Fatty Acids in 1 minute
Peroxide Value in 4 minutes
p-Anisidine Value in 2 minutes
Soaps in 2 minutes

Where can I buy the CDR FoodLab for Oils & Fat instrument?

The CDR FoodLab for Oils & Fat instrument is available from Everest Instruments Pvt. Ltd. is their exclusive authorized distributor.
